About HID^® ActivClient^® for macOS 9.7

ActivClient is middleware for smart cards and USB tokens that allows enterprise and government customers to easily use security devices to secure workstations and networks.

ActivClient enables the use of PKI certificates and keys, one-time passwords and static password credentials stored on a smart card or a USB key to secure:

Desktop applications	Web logon
Network logon	Electronic transactions
Remote access

Components

ActivClient consists of the following components:

• ActivClient Console: Provides a management GUI for your security devices and credentials.

• ActivClient CryptoTokenKit (CTK): Provides native macOS PKI Public Key Infrastructure. A framework that enables secure, electronic identities through the use of public key cryptography, including the creation, distribution, and management of digital certificates. capabilities for all tokens supported by ActivClient, including PIN authentication, smart card logon, and email protection.

• ActivClient BSI: Used by legacy applications to access the services provided by applets stored on a supported smart card or key.

• PKCS#11 support: Provides smart card support for applications relying on the PKCS#11 API.

  The PKCS#11 .dylib file is located in the following directory:

  /Applications/ActivClient CryptoTokenKit.app/Contents/Resources/libactivclient-pkcs11.dylib

Operating Systems

• macOS 14 and later, compatible with both Intel and Apple Silicon chips

Supported Smart Cards and Keys

This version of ActivClient supports the following smart cards and USB security keys:

HID Global/ActivID

• Crescendo 2300 Card

• Crescendo Key (2300 Series)

• Crescendo 4000 Card

• Crescendo Key V3 (4000 Series)

• Crescendo Key FIPS

• Crescendo Key FIPS CL

• Crescendo 144K Card

• Crescendo 144K FIPS

• Crescendo 1150 Card

Other Supported Cards and Keys

• Idemia ID-One Cosmo v8.0 with PIV 2.3.5 / 2.4.0

• Idemia ID-One Cosmo v8.1 with PIV 2.4.1

• Idemia ID-One Cosmo v8.2 with PIV 2.4.2

• Idemia ID-One Cosmo v8.1 with PIV 2.4.1 CL

• Idemia ID-One Cosmo v8.2 with PIV 2.4.2 CL

• Idemia ID-One PIV 243

• Idemia ID-One PIV 243 CL

• Thales IDCore 3230

• U.S. Government PIV-mode cards

• YubiKey

• YubiKey FIPS

• YubiKey 5

Supported Smart Card Readers

ActivClient supports all HID Global smart card readers (Contact, Contactless, and Dual-Interface). The following list is indicative and not exhaustive:

• OMNIKEY^® contact readers:

  • 3021 USB

  • 3121 USB

  • 6121 Mobile USB (SIM-size contact)

  • ActivKey SIM

• OMNIKEY^® contactless readers:

  • 5022 CL

  • 5427 CK
