Issuer-Responder Mapping Values

This table lists registry values that define the issuer in an issuer-responder mapping. The IssuerName, SerialNumber and PublicKey values represent encoded information contained in the Issuer certificate. This information cannot be entered manually. To add an Issuer-Responder mapping, use the management console to create the mapping on a local computer, then use the copy and paste functions to enter the appropriate values for use in setting remote registry entries. The following figure depicts a configuration using two issuer-responder mappings, including a mapping that contains two responders in a given issuer-responder mapping:

HKEY_LOCAL_MACHINE\SOFTWARE\HID Global\SerVESettings\IRCerts:

Name	Management Console Property	Default	Definition
certificate-number 0 represents the first issuer certificate used in any issuerresponder mappings. 1 represents the second issuer certificate used in any issuerresponder mappings, and so on.	N/A	N/A	The hex encoded DER certificate of the issuer.

HKEY_LOCAL_MACHINE\SOFTWARE\HID Global\SerVESettings\IRMappings\ir-mapping-number:

Name	Management Console Property	Default	Definition
DisplayName	N/A	N/A	The display name of the certificate. The Management Console sets this to the CN of the distinguished name in the certificate, but the administrator can set any display name desired.
CertStore	N/A	N/A	The name of the certificate store where the certificate is located. The IssuerName, SerialNumber, and PublicKey values are used to retrieve the appropriate certificate from the store.
IssuerName	N/A	N/A	The hex encoded binary name of the certificate’s issuer.
SerialNumber	N/A	N/A	The hex serial number of the certificate.
PublicKey	N/A	N/A	The hex encoded binary public key of the certificate.

This table lists the registry values that define the responder(s) in an issuer responder mapping.

HKEY_LOCAL_MACHINE\SOFTWARE\HID Global\SerVESettings\IRMappings\ir-mapping-number\Responders\responder-number:

Name	Management Console Property	Default	Definition
responder-number 0 represents the first responder in the issuerresponder mapping. 1 represents the second responder in the mapping, and so on.	N/A	N/A	The URL of the OCSP responder in an issuerresponder mapping.
